Tensile Strength: 270/360 Ibs
Width: 10~16 mm
Length: 150mm~1000mm
Engineered for critical applications where failure is not an option, our Ball Lock Stainless Steel Cable Ties provide a permanent, vibration-proof fastening solution. The unique ball locking mechanism creates an irreversible, ultra-secure lock that withstands extreme stress and impact, making it ideal for heavy-duty bundling in construction, marine, and industrial machinery. Available in practical lengths from 150 to 1000mm and constructed from corrosion-resistant grades 201, 304, 316, or 316L, these ties deliver unmatched tensile strength ranging from 1200 to 1600 N. They perform reliably in temperatures from -60°C to 150°C, ensuring long-term safety and stability in the most demanding environments.
• All length are available, Stainless steel type: 201, 304, 316, 316L, Special sizes can be customized;
• Characteristic: They have an unique ball locking mechanism that allow easily and quickly installedand not undone, High tensile strength; Non-flammability High resistance to acetic acid, alkali acidsulphuric acid.corrode ...etc;
• Working temperature: -60°C~150°C
| Part No. | Approx.Length mm(inch) |
Approx.Width mm(inch) |
Max.Bundle Dia mm(inch) |
Min. loop Tensile Strength N(Ibs) |
| JXC-10×150 | 150(5.9) | 10(0.39) | 37(1.46) | 1200(270) |
| JXC-10×200 | 200(7.87) | 50(1.97) | ||
| JXC-10×250 | 250(9.84) | 63(2.48) | ||
| JXC-10×300 | 300(11.8) | 76(2.99) | ||
| JXC-10×350 | 350(13.78) | 89(3.5) | ||
| JXC-10×400 | 400(15.75) | 102(4.02) | ||
| JXC-10×450 | 450(17.72) | 115(4.53) | ||
| JXC-10×500 | 500(19.69) | 128(5.04) | ||
| JXC-10×550 | 550(21.65) | 141(5.55) | ||
| JXC-10×600 | 600(23.62) | 154(6.06) | ||
| JXC-10×650 | 650(25.59) | 167(6.57) | ||
| JXC-10×700 | 700(27.56) | 180(7.09) | ||
| JXC-10×750 | 750(29.53) | 191(7.52) | ||
| JXC-10×800 | 800(31.5) | 193(7.59) | ||
| JXC-12×200 | 200(7.87) | 12(0.472) | 50(1.97) | 1200(270) |
| JXC-12×250 | 250(9.84) | 63(2.48) | ||
| JXC-12×300 | 300(11.8) | 76(2.99) | ||
| JXC-12×350 | 350(13.78) | 89(3.5) | ||
| JXC-12×400 | 400(15.75) | 102(4.02) | ||
| JXC-12×450 | 450(17.72) | 115(4.53) | ||
| JXC-12×500 | 500(19.69) | 128(5.04) | ||
| JXC-12×550 | 550(21.65) | 141(5.55) | ||
| JXC-12×600 | 600(23.62) | 154(6.06) | ||
| JXC-12×650 | 650(25.59) | 167(6.57) | ||
| JXC-12×700 | 700(27.56) | 180(7.09) | ||
| JXC-16×200 | 200(7.87) | 16(0.63) | 50(1.97) | 1600 |
| JXC-16×250 | 250(9.84) | 63(2.48) | ||
| JXC-16×300 | 300(11.8) | 76(2.99) | ||
| JXC-16×350 | 350(13.78) | 89(3.5) | ||
| JXC-16×400 | 400(15.75) | 102(4.02) | ||
| JXC-16×450 | 450(17.72) | 115(4.53) | ||
| JXC-16×500 | 500(19.69) | 128(5.04) | ||
| JXC-16×550 | 550(21.65) | 141(5.55) | ||
| JXC-16×600 | 600(23.62) | 154(6.06) | ||
| JXC-16×650 | 650(25.59) | 167(6.57) | ||
| JXC-16×700 | 700(27.56) | 180(7.09) | ||
| JXC-16×750 | 750(29.53) | 191(7.52) | ||
| JXC-16×800 | 800(31.5) | 193(7.59) | ||
| JXC-16×1000 | 1000(39.37) | 206(8.11) |
