Tensile Strength: 200lbs~270lbs
Width: 4.6mm~7.9mm
Length: 150mm~800mm
Technical information
Material: Stainless Steel Grade 304 or 316
Coating: Polyester/Epoxy, Nylon 11:
Working Temp:-80°C to 150°C;
Description: Entirely Black;
Flammability: Fireproof;
Other Properties: UV-resistant, Halogen
free, non-toxic.
Product Feature
The fully coated version will prevent
static electricity.
A polyester-coated band provides additional
edge protection, to prevent corrosion
between dissimilar materials.
| Part No. | Approx.Length mm(inch) |
Approx.Width mm(inch) |
Max.Bundle Dia mm(inch) |
Min. loop Tensile Strength N(Ibs) |
| JXCP-4×150 | 150(5.9) | 4.0 | 37(1.46) | 1000 |
| JXCP-4×200 | 200(7.87) | 50(1.97) | ||
| JXCP-4×250 | 250(9.84) | 63(2.48) | ||
| JXCP-4×300 | 300(11.8) | 76(2.99) | ||
| JXCP-4×350 | 350(13.78) | 89(3.5) | ||
| JXCP-4×400 | 400(15.75) | 102(4.02) | ||
| JXCP-4×450 | 450(17.72) | 115(4.53) | ||
| JXCP-4×500 | 500(19.69) | 128(5.04) | ||
| JXCP-4×550 | 550(21.65) | 141(5.55) | ||
| JXCP-4×600 | 600(23.62) | 154(6.06) | ||
| JXCP-4.6×150 | 150(5.9) | 4.6(0.181) | 37(1.46) | 1000 |
| JXCP-4.6×200 | 200(7.87) | 50(1.97) | ||
| JXCP-4.6×250 | 250(9.84) | 63(2.48) | ||
| JXCP-4.6×300 | 300(11.8) | 76(2.99) | ||
| JXCP-4.6×350 | 350(13.78) | 89(3.5) | ||
| JXCP-4.6×400 | 400(15.75) | 102(4.02) | ||
| JXCP-4.6×450 | 450(17.72) | 115(4.53) | ||
| JXCP-4.6×500 | 500(19.69) | 128(5.04) | ||
| JXCP-4.6×550 | 550(21.65) | 141(5.55) | ||
| JXCP-4.6×600 | 600(23.62) | 154(6.06) | ||
| JXCP-7.9×150 | 150(5.9) | 7.9(0.311) | 37(1.46) | 1200(270) |
| JXCP-7.9×200 | 200(7.87) | 50(1.97) | ||
| JXCP-7.9×250 | 250(9.84) | 63(2.48) | ||
| JXCP-7.9×300 | 300(11.8) | 76(2.99) | ||
| JXCP-7.9×350 | 350(13.78) | 89(3.5) | ||
| JXCP-7.9×400 | 400(15.75) | 102(4.02) | ||
| JXCP-7.9×450 | 450(17.72) | 115(4.53) | ||
| JXCP-7.9×500 | 500(19.69) | 128(5.04) | ||
| JXCP-7.9×550 | 550(21.65) | 141(5.55) | ||
| JXCP-7.9×600 | 600(23.62) | 154(6.06) | ||
| JXCP-7.9×650 | 650(25.59) | 167(6.57) | ||
| JXCP-7.9×700 | 700(27.56) | 180(7.09) | ||
| JXCP-7.9×750 | 750(29.53) | 191(7.52) | ||
| JXCP-7.9×800 | 800(31.5) | 193(7.59) |
