Tensile Strength: 18Ibs~50Ibs
Width: 2.6mm~4.7mm
Length: 100mm~350mm
Material: Made of nylon 66 material approved by UL. The fire protection rating is 94V-2. It is resistant to acids and corrosion, has good insulation properties, is not easy to age, and has strong bearing capacity.
Applicable temperature:- 40°C to 150°C
Color: The standard color is the natural color (light green). Special colors are available for customization.
Features: It has excellent high and low temperature resistance performance, and can maintain stable physical and chemical properties within a wide temperature range. It also has the characteristics of high strength, high toughness, wear resistance, anti-aging, and good insulation. It is widely used in the fixation and bundling of cables, pipelines, etc. in fields such as electronics and electrical appliances, automobile manufacturing, aerospace, construction engineering, and shipbuilding.
| Size | Width | Lenght | Max.Bundle Dia. | Min.Loop Tesile Strength | ||||
| mm | inch | mm | inch | mm | inch | kgs | lbs | |
| 3*100 | 2.6 | 0.1 | 100 | 3.94 | 22 | 0.87 | 8 | 18 |
| 3*150 | 2.6 | 0.1 | 150 | 5.91 | 35 | 1.38 | 8 | 18 |
| 4*150 | 3.5 | 0.14 | 150 | 5.91 | 35 | 1.38 | 18 | 40 |
| 4*200 | 3.5 | 0.14 | 200 | 7.87 | 53 | 2.09 | 18 | 40 |
| 4*300 | 3.6 | 0.14 | 300 | 11.81 | 80 | 3.15 | 18 | 40 |
| 5*200 | 4.6 | 0.18 | 200 | 7.87 | 53 | 2.09 | 22 | 50 |
| 5*250 | 4.6 | 0.18 | 250 | 9.84 | 65 | 2.56 | 22 | 50 |
| 5*300 | 4.7 | 0.19 | 300 | 11.81 | 82 | 3.23 | 22 | 50 |
| 5*350 | 4.7 | 0.19 | 350 | 13.78 | 90 | 3.54 | 22 | 50 |
