Tensile Strength: 18Ibs~175Ibs
Width: 2.6mm~8.8mm
Length: 100mm~630mm
Material: Made of nylon 66 material approved by UL. The fire resistance rating is 94V-2. It has good acid resistance, corrosion resistance,excellent insulation, is not easy to age, and has a strong load-bearing capacity.
Applicable temperature: -40°C to 85°C.
Color: The standard color is natural color (white). Customization of special colors is supported.
Features: Suitable for use in low-temperature environments. For example, in the freezing cold of Russia,or in cold chain systems, freezers, etc.
| Size | Width | Lenght | Max.Bundle Dia. | Min.Loop Tesile Strength | ||||
| mm | inch | mm | inch | mm | inch | kgs | lbs | |
| 3*100 | 2.6 | 0.1 | 100 | 3.94 | 22 | 0.87 | 8 | 18 |
| 4*200 | 3.5 | 0.14 | 200 | 7.87 | 53 | 2.09 | 18 | 40 |
| 4*300 | 3.6 | 0.14 | 300 | 11.81 | 80 | 3.15 | 18 | 40 |
| 5*200 | 4.6 | 0.18 | 200 | 7.87 | 50 | 1.97 | 22 | 50 |
| 5*250 | 4.7 | 0.19 | 250 | 9.84 | 65 | 2.56 | 22 | 50 |
| 5*300 | 4.6 | 0.18 | 300 | 11.81 | 80 | 3.15 | 22 | 50 |
| 5*350 | 4.7 | 0.19 | 350 | 13.78 | 90 | 3.54 | 22 | 50 |
| 8*200 | 7.6 | 0.3 | 200 | 7.87 | 50 | 1.97 | 55 | 120 |
| 8*250 | 7.6 | 0.3 | 250 | 9.84 | 65 | 2.56 | 55 | 120 |
| 8*300 | 7.6 | 0.3 | 300 | 11.81 | 80 | 3.15 | 55 | 120 |
| 10*300 | 8.8 | 0.35 | 300 | 11.81 | 110 | 4.33 | 80 | 175 |
| 10*435 | 8.8 | 0.35 | 435 | 17.13 | 120 | 4.72 | 80 | 175 |
| 10*630 | 8.8 | 0.35 | 630 | 24.8 | 180 | 7.09 | 80 | 175 |
