Tensile Strength: 18Ibs~120Ibs
Width: 2.5mm~7.6mm
Length: 100mm~250mm
Material: Made of UL-approved nylon 66 material. It has a fire rating of 94V- 2, and features acid resistance, corrosion resistance, good insulation, resistance to aging, high load- bearing capacity, and UV resistance.
Applicable temperature range:- 40°C to 85°C.
Colors: The standard colors are natural color or black. Customization of special colors is supported.
Feature: are centered on UV resistance and anti-aging properties, combined with high strength and weather tolerance, widely used in outdoor, construction, agriculture, and other scenarios with prolonged sunlight exposure, ensuring secure cable and equipment fastening and long-lasting durability.
| Size | Width | Lenght | Max.Bundle Dia. | Min.Loop Tesile Strength | ||||
| mm | inch | mm | inch | mm | inch | kgs | lbs | |
| 3*100 | 2.5 | 0.1 | 100 | 3.94 | 22 | 0.87 | 8 | 18 |
| 4*200 | 3.6 | 0.14 | 200 | 7.87 | 53 | 2.09 | 18 | 40 |
| 4*300 | 3.6 | 0.14 | 300 | 11.81 | 80 | 3.15 | 18 | 40 |
| 5*200 | 4.8 | 0.19 | 200 | 7.87 | 50 | 1.97 | 22 | 50 |
| 5*250 | 4.8 | 0.19 | 250 | 9.84 | 65 | 2.56 | 22 | 50 |
| 5*300 | 4.8 | 0.19 | 300 | 11.81 | 80 | 3.15 | 22 | 50 |
| 5*350 | 4.8 | 0.19 | 350 | 13.78 | 90 | 3.54 | 22 | 50 |
| 8*200 | 7.6 | 0.3 | 200 | 7.87 | 50 | 1.97 | 55 | 120 |
| 8*250 | 7.6 | 0.3 | 250 | 9.84 | 65 | 2.56 | 55 | 120 |
