Description

• Maximum withstand voltage: 105℃, 300VOLTS MAX.

• Terminal material: Tin-plated stainless steel.

Product Dimensions

A.W.G	Item No.	DIMENSION						French colors German colors
mm²	Item No.	F	L	W	B	D	C	French colors German colors
2×22 A.W.G 2×0.5 mm²	TE0508	8	14.5	5	6.5	1.8	1.5	White Orange
2×20 A.W.G 2×0.75 mm²	TE7508	8	14.5	5.5	6.7	2.1	1.8	Blue White
2×20 A.W.G 2×0.75 mm²	TE7510	10	16.7	5.5	6.7	2.1	1.8	Blue White
2×18 A.W.G 2×1.0 mm²	TE1008	8	15.1	5.5	7.1	2.3	2	Red Yellow
2×18 A.W.G 2×1.0 mm²	TE1010	10	17.1	5.5	7.1	2.3	2	Red Yellow
2×16 A.W.G, 2×1.5 mm²	TE1508	8	15.5	6.4	7.2	2.6	2.3	Black Red
2×16 A.W.G, 2×1.5 mm²	TE1512	12	19.5	6.4	7.2	2.6	2.3	Black Red
2×14 A.W.G 2×2.5 mm²	TE2510	10	18.5	8	8.5	3.3	2.9	Gray Blue
2×14 A.W.G 2×2.5 mm²	TE2513	13	21.5	8	8.5	3.3	2.9	Gray Blue
2×12 A.W.G 2×4mm²	TE4012	12	23.1	8.8	111	4.2	3.8	Orange Gray
2×10 A.W.G 2×6mm²	TE6014	14	26.1	9.5	12.1	5.3	4.9	Black Green
2×8 A.W.G 2×10mm²	TE10-14	14	26.6	12.6	12.6	6.9	6.5	Brown Off-white
2×6 A.W.G 2×16mm²	TE16-14	14	31.3	19	17.3	8.7	8.3	Off-white Green
